Toyota Camry fuse are a class of fuses used to protect the wiring and electrical equipment for vehicles. If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary.
Passenger Compartment Fuse Box
The fuse box is located under the instrument panel (on the driver’s side), under the cover.
| № | Name | Amp | Circuit |
|---|---|---|---|
| 1 | ECU-IG1 NO.2 | 10 | Shift lock control system, seat heaters, smart key system, tire pressure warning system, wireless remote control, multiplex communication system, audio system, navigation system, moon roof, auto anti-glare inside rear view mirror |
| 2 | ECU-IG1 NO.1 | 10 | Vehicle stability control system, electric cooling fans, steering sensor, multiport fuel injection system/ sequential multiport fuel injection system, charging system, rear window defogger, outside rear view mirror defoggers, Blind Spot Monitor |
| 3 | PANEL | 10 | Switch illumination, air conditioning system, shift lever light, glove box light, interior lights, personal lights, audio system, navigation system |
| 4 | TAIL | 15 | Parking lights, side marker lights, tail lights, license plate lights, fog lights |
| 5 | EPS-IG1 | 7.5 | Electric power steering |
| 5 | DOOR R/R | 20 | Rear right-hand power windows |
| 6 | ECU-IG1 NO.3 | 7.5 | Blind Spot Monitor |
| 6 | DOOR F/L | 20 | Front left-hand power windows, outside mirror control ECU |
| 7 | S/HTR&FAN F/L | 10 | Seat heaters |
| 7 | DOOR R/L | 20 | Rear left-hand power windows |
| 8 | H-LP LVL | 7.5 | Automatic headlight leveling system |
| 9 | WASHER | 10 | Windshield wipers and washer |
| 10 | A/C-IG1 | 7.5 | Air conditioning system |
| 11 | WIPER | 25 | Windshield wipers and washer |
| 12 | BKUP LP | 7.5 | Back-up lights, multiport fuel injection system/sequential multiport fuel injection system, electronic controlled transmission, audio system, navigation system |
| 13 | DOOR NO.1 | 30 | Power windows |
| 14 | WIPER-S | 5 | No circuit |
| 14 | EPS-IG1 | 7.5 | Electric power steering |
| 15 | P/OUTLET RR | 20 | Power outlet |
| 16 | SFT LOCK-ACC | 5 | Shift lock control system |
| 17 | DOOR R/R | 20 | Rear right-hand power windows |
| 17 | S./HTR&FAN F/R | 10 | Seat heaters (front right) |
| 18 | DOOR R/L | 20 | Rear left-hand power windows |
| 18 | S/HTR&FAN F/L | 10 | Seat heaters (front left) |
| 19 | OBD | 10 | On-Board diagnosis system |
| 20 | ECU-B NO.2 | 10 | Smart key system, tire pressure warning system |
| 21 | DOOR NO.2 | 20 | Power windows |
| 22 | AM1 | 7.5 | Multiport fuel injection system/ sequential multiport fuel injection system, starter system |
| 23 | STOP | 7.5 | Tail lights, multiport fuel injection system/sequential multiport fuel injection system, vehicle stability control system, anti-lock brake system, electronic controlled transmission, high mounted stoplight, smart key system, shift lock control system |
| 24 | P/SEAT RR | 30 | No circuit |
| 25 | A/C -B | 7.5 | Air conditioning system |
| 26 | S/ROOF | 10 | Moon roof |
| 27 | P/SEAT FR | 30 | Power seats |
| 28 | PSB | 30 | No circuit |
| 29 | D/L-AM1 | 20 | Multiplex communication system, power door lock, trunk opener switch |
| 30 | TI&TE | 20 | No circuit |
| 31 | A/B | 10 | Front passenger occupant classification system, SRS airbag system |
| 32 | ECU-IG2 NO.1 | 7.5 | Multiport fuel injection system/ sequential multiport fuel injection system |
| 33 | ECU-IG2 NO.2 | 7.5 | Smart key system, Blind Spot Monitor |
| 34 | CIG&P/ OUTLET | 15 | Power outlet |
| 35 | ECU-ACC | 7.5 | Clock, outside rear view mirrors, multiplex communication system, audio system, navigation system |
| 36 | S/HTR&FAN FI R | 10 | Seat heaters |
| 37 | S/HTR RR | 20 | No circuit |
| 38 | DOOR F/R | 10 | Front right-hand power windows, outside mirror control ECU |
| 39 | ECU-IG1 NO.3 | 7.5 | No circuit |
Fuse Box in the Engine Compartment
It is located in the engine compartment (left-side).
| № | Name | Amp | Circuit |
|---|---|---|---|
| 1 | METER-IG2 | 5 | Gauge and meters |
| 2 | FAN | 50 | 2GR-FE: Electric cooling fans |
| 3 | H-LPCLN | 30 | No circuit |
| 4 | HTR | 50 | Air conditioning system |
| 5 | ALT | 120 | Charging system |
| 6 | ABS NO.2 | 30 | Vehicle stability control system |
| 7 | ST/AM2 | 30 | Starter system, ECU-IG2 NO.1, A/B, ECU-IG2 NO.2 |
| 8 | H-LP-MAIN | 30 | H-LP LH-LO, H-LP RH-LO, MNL H-LP LVL, headlights (low beam) |
| 9 | ABS NO.1 | 50 | Vehicle stability control system |
| 10 | EPS | 80 | Electric power steering |
| 11 | S-HORN | 7.5 | S-HORN |
| 12 | HORN | 10 | Horns |
| 13 | EFI NO.2 | 15 | Multiport fuel injection system/ sequential multiport fuel injection system, electronic controlled transmission |
| 14 | EFI NO.3 | 7.5 | 2AR-FE: Multiport fuel injection system/ sequential multiport fuel injection system |
| 14 | EFI NO.3 | 10 | 2GR-FE: Multiport fuel injection system/ sequential multiport fuel injection system |
| 15 | INJ | 7.5 | Multiport fuel injection system/ sequential multiport fuel injection system |
| 16 | ECU-IG2 NO.3 | 7.5 | Multiport fuel injection system/ sequential multiport fuel injection system, steering lock system, electronic controlled transmission |
| 17 | IGN | 15 | Starter system |
| 18 | D/L-AM2 | 20 | No circuit |
| 19 | IG2-MAIN | 25 | IGN, INJ, METER-IG2, ECU-IG2 NO.3, A/B, ECU-IG2 NO.2, ECU-IG2 NO.1 |
| 20 | ALT-S | 7.5 | Charging system |
| 21 | MAYDAY | 5 | MAYDAY |
| 22 | TURN&HAZ | 15 | Turn signal lights, emergency flashers, gauge and meters |
| 23 | STRG LOCK | 10 | Steering lock system |
| 24 | AMP | 15 | Audio system |
| 25 | H-LP LH-LO | 15 | Halogen headlight: Left-hand headlight (low beam), manual headlight leveling system |
| 25 | H-LP LH-LO | 20 | Discharge headlight: Left-hand headlight (low beam), manual headlight leveling system |
| 26 | H-LP RH-LO | 15 | Halogen headlight: Right-hand headlight (low beam) |
| 26 | H-LP RH-LO | 20 | Discharge headlight: Right-hand headlight (low beam) |
| 27 | MNL H-LP LVL | 7.5 | Discharge headlight: Manual headlight leveling system |
| 28 | EFI-MAIN NO.1 | 30 | Multiport fuel injection system/ sequential multiport fuel injection system, EFI NO.2, EFI NO.3, A/F sensor |
| 29 | SMART | 5 | No circuit |
| 30 | ETCS | 10 | Electronic throttle control system |
| 31 | TOWING | 20 | No circuit |
| 32 | EFI NO.1 | 7.5 | Multiport fuel injection system/ sequential multiport fuel injection system, electronic controlled transmission |
| 33 | EFI-MAIN NO.2 | 20 | 2AR-FE: A/F sensor |
| 33 | A/F | 20 | 2GR-FE: A/F sensor |
| 34 | AM 2 | 7.5 | Smart key system |
| 35 | RADIO-B | 20 | Audio system, navigation system |
| 36 | DOME | 7.5 | Clock, vanity lights, interior lights, personal lights, trunk light, door courtesy lights |
| 37 | ECU-B NO.1 | 10 | Multiplex communication system, smart key system, gauge and meters, tire pressure warning system, wireless remote control, steering sensor, front passenger occupant classification system, Blind Spot Monitor |
Checking and replacing fuses
If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary.
- Turn the engine switch off.
- Open the fuse box cover.
- Remove the fuse with the pull-out tool.
- Check if the fuse is blown.
- After a fuse is replaced
- If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement.
- If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer.
- If there is an overload in a circuit
- The fuses are designed to blow, protecting the wiring harness from damage.
WARNING
- To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to the vehicle, and possibly a fire or injury.- Never use a fuse of a higher amperage rating than that indicated, or use any other object in place of a fuse.
- Always use a genuine Toyota fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix. - Do not modify the fuses or fuse boxes.
